86 Nema 34 Stepper Motor
| 86 Nema 34 Stepper Motor |
Three-phase 86 series Nema 34 hybrid stepping motor, the use of high-quality raw materials and high-specification permanent magnet silicon steel, with high positioning accuracy, output torque, fast response, low noise, good dynamic characteristics, quality and reliable. Motor length 98mm ~ 150mm between the torque range: 5N.m ~ 9N.m, motor shaft diameter 14mm.
| Model No. | Step Angle | Length | Voltage/phase | Current/Phase | Resistance/Phase | Inductance/Phase | Holding Torque | Rotor Inertia |
of Leads | Weight |
| unit | 。 | mm | V | A | Ω | mH | N.m | g-cm2 | # | kg |
| 86BYG350-98 | 1.2 | 98 | 3.2 | 5.8 | 0.55 | 2.95 | 5 | 2300 | 3 | 2.7 |
| 86BYG350-113 | 113 | 3.7 | 5.8 | 0.64 | 4.55 | 6.5 | 2600 | 3 | 3.5 | |
| 86BYG350-128 | 128 | 4.4 | 5.8 | 0.75 | 5.00 | 7.3 | 3400 | 3 | 4.0 | |
| 86BYG350-150 | 150 | 5.2 | 5.8 | 0.89 | 6.90 | 9 | 4600 | 3 | 5.1 | |
| 86BYG350-98H | 98 | 16.2 | 3.0 | 5.40 | 15.00 | 5 | 2320 | 3 | 2.8 | |
| 86BYG350-113H | 113 | 6.9 | 3.0 | 2.30 | 10.00 | 6 | 2620 | 3 | 3.7 | |
| 86BYG350-128H | 128 | 7.4 | 3.0 | 2.48 | 13.90 | 7 | 3480 | 3 | 4.0 | |
| 86BYG350-150H | 150 | 10.8 | 3.0 | 2.70 | 21.00 | 9 | 4650 | 3 | 5.2 |
Suitable to Glue Dispenser, sewing machine, CNC Lathe Machine, embroidering machine and so on.
